Koncept Zeke V3 Polo Bike Frame
*Please note there is a wait time after ordering this frame for it to arrive, please contact us for accurate delays*
The Zeke V3 bike frame by Koncept is THE bike polo frame. Specifically designed with endos and quick turns in mind, this frame's unique geometry has been fully optimized for tight maneuvering to get you wherever you need to be on the court.
SPECS:
Material: 6061 Alluminum Alloy
Seattube Size: S: 46.5cm M: 50cm
Wheel: S: 26" M: 26" / 650B
Top Tube: S: 51.5cm M: 54.5cm
Seat Angle: S: 75° M: 74°
Head Angle: S: 74° M: 74.5°
Headtube Length: S: 13cm M: 15.5cm
Headtube Diameter: 1-1/2" to 1-1/8"
Bottom Bracket Drop:
S: 28 M: 25
Chainstay Length:
S: 34cm M: 35.5cm
Front Center:
S: 539 M: 560
Wheelbase:
S: 882 M: 913
Weight:
S: 1570g M: 1671g
Max Tire Clearance:
S: 26x1.35 M: 26x1.50 / 650/28B
BB width: 73mm English Thread
Seatpost Diameter: 27.2cm
Seat Clamp Diameter: 31.8cm
Rear End Spacing: 135
Rear Dropout Travel: 40mm
